20W Portable Handheld Laser Marker

Basic Information
Place of Origin: Guangdong, China
Brand Name: DAPENG
Certification: CE, ISO
Model Number: YLP-20
Minimum Order Quantity: 1 set
Price: USD1000-1500
Packaging Details: Plywood box
Delivery Time: 5-10 days
Payment Terms: T/T
Supply Ability: 150 sets per month
Detail Information
Application: Laser Marking Working Accuracy: 0.01mm
Graphic Format Supported: AI, BMP, DXF, HPGL Laser Type: Fiber Laser
Condition: New CNC Or Not: Yes
Cooling Mode: Air Cooling Control Software: Linux
Laser Source Brand: MAX Control System Brand: Linux
Weight (KG): 7 KG Key Selling Points: Easy To Operate
Warranty: 1 Years Marking Area: 100mm*100mm
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 2 Years Core Components: Laser Source
Mode Of Operation: Pulsed Configuration: Hand-held
Feature: Automated Loading Product Name: Handheld Laser Marking Machine
Advantage: Portable-type And High-accuracy Wavelength: 1064nm
Source: 110V/220V AC Package Size: 525cm*423cm*310cm
Marking Range: 70mm*70mm 100mm*100mm(optional) Output Power: 20W/30W
Highlight:

20W Portable Handheld Laser Marker

,

30W Portable Handheld Laser Marker

,

Stable Hand Held Laser Marker


Product Description

DAPENG 20W 30W handheld laser Mini Laser Marking Portable Laser Engraving Machines
Product Description
Item
Value
Product name
Handheld laser marking machine
Advantage
Portable-type and high-accuracy
Source
110V/220V AC. lithium cell(216wh)
Marking range
70mm*70mm 100mm*100mm(optional)
Output Power
20W/25W/30W
Applied materials
Variours metals,Plastic,Glass,Wood,Leather,Aluminum products,Paper
Package
Laser, marking card, handheld galvanometer, battery, focusing ring, instruction manual, packaging cotton, packaging paper box,
electrical accessories, plastic casing mold opening
Set position square type
Red light set position right coke



Features:

1. Excellent light quality:
Comparing with traditional solid laser marking machine, angle of divergence is only 1/4 of diode pump laser device. It is especially suitable for precision marking.
2. Low usage cost:
Photo electric conversion efficiency max is 30%, whole machine power consumption is less than 500W, it is the 1/10 of laser pump lamp marking machine. It greatly saves the cost in power consumption.
3. Free maintenance & long service life:
Using laser diode as the source of pump, full sealing light path design, its average no-failure operation is over 100 thousand hours.





20W Portable Handheld Laser Marker 0
20W Portable Handheld Laser Marker 1
20W Portable Handheld Laser Marker 2
20W Portable Handheld Laser Marker 3
20W Portable Handheld Laser Marker 4
20W Portable Handheld Laser Marker 5
20W Portable Handheld Laser Marker 6
20W Portable Handheld Laser Marker 7
20W Portable Handheld Laser Marker 8
20W Portable Handheld Laser Marker 9
20W Portable Handheld Laser Marker 10
20W Portable Handheld Laser Marker 11
20W Portable Handheld Laser Marker 12
20W Portable Handheld Laser Marker 13
20W Portable Handheld Laser Marker 14
Company Profile
Shenzhen Dapeng Laser Technology Co, Ltd. was established in 2011. It is a laser equipment high-tech enterprise that integrates R&D, manufacturing, sales and service. It is dedicated to laser process R&D, laser equipment design R&D, production, technical support, service and consulting. Our company's main products include: laser cutting machine, laser welding machine, laser marking machine, industry-specific and automated laser equipment, etc, applied to electronics, IC chips, electrical appliances, lighting fixtures, jewelry, hardware tools, sanitary ware, instruments Instrumentation, automobile and motorcycle accessories, mobile phone communications components, molds, precision machinery, medical equipment, IT digital, metal housing, military aviation components, garment leather, craft gifts, advertising decoration, models, cookware, kitchen utensils and other industries. Dapeng laser product quality are stable and reliable, with a professional R & D team, while pursuing excellent quality, Dapeng laser also provides customers with timely, comfortable pre-sale, sales, after-sales service and excellent cost-effective products. Dapeng Laser has won the trust and praise of customers by implementing the business philosophy of "helping customers succeed, creating value models, and building industrial laser equipment industry to serve high-end brands". Customers are located throughout the country and overseas. In 2016, sold more than 5,000 laser equipment. Our company has established a complete production and sales and after-sales service system, has production bases in Shenzhen, Wenzhou,Kunshan and Xiamen, has a large-scale laser cutting machine production base in Dongguan, and has offices in major domestic industrial cities and regions. There are equipment demonstrations, process proofing, sales and after-sales services, and resident technical service personnel, to provide customers with timely, comfortable pre-sales, sales, after-sales support and services.
20W Portable Handheld Laser Marker 15
20W Portable Handheld Laser Marker 16
20W Portable Handheld Laser Marker 17
Our Workshop
20W Portable Handheld Laser Marker 18
20W Portable Handheld Laser Marker 19
Why Choose US
Dapeng Laser has established a complete production and sales and after-sales service system, has production bases in Shenzhen, Wenzhou,Kunshan and Xiamen, has a large-scale laser cutting machine production base in Dongguan, and has offices in major domestic industrial cities and regions. There are equipment demonstrations, process proofing, sales and after-sales services, and resident technical service personnel, to provide customers with timely, comfortable pre-sales, sales, after-sales support and services. Dapeng people know that quality and service are fundamental to the survival of the company. Innovation is the foundation for the long-tem development of the company. It helps customers create value and strives to build a well-known brand in the laser equipment industry.
20W Portable Handheld Laser Marker 20
20W Portable Handheld Laser Marker 21
Laser Welding Machine Team
20W Portable Handheld Laser Marker 22
Laser Cutting Machine Team
20W Portable Handheld Laser Marker 23
Oversea Marketing Team
Our Exhibition
20W Portable Handheld Laser Marker 24
20W Portable Handheld Laser Marker 25
20W Portable Handheld Laser Marker 26
20W Portable Handheld Laser Marker 27
Our Certificates
20W Portable Handheld Laser Marker 28
CE
20W Portable Handheld Laser Marker 29
ISO
20W Portable Handheld Laser Marker 30
20W Portable Handheld Laser Marker 31
20W Portable Handheld Laser Marker 32
20W Portable Handheld Laser Marker 33
Packing & Delivery
We support to ship via Sea, Railway,Air, Express(UPS, DHL, EMS, Swiss Post, HongKong Post, FedEx, TNT). You also can choose the shipping method you like if you prefer another courier.
20W Portable Handheld Laser Marker 34
FAQ:
Q1: How do I know which model is suitable for my product application?
You just need to tell us the following information then we can offer you a suitable solution? In addition, you can also send us the sample and we will arrange professional engineers for proofing evaluation
1) What is your product? material? thickness? required accuracy?
2) What is the current production process?
3) What is your desired budget and delivery time.
Q2: When I get this machine, but I don't know how to use it. What should I do?
We will send teaching video of both installation and operation, as well as the English manual. If you have further questions, we have engineers who can speak English can serve you on-line directly. And for some countries , like in India, Malaysia,
Korea,Spain, we have local support team, more countries will be in the picture soon.
Q3: How can I do if the machine goes wrong?
We guarantee machine quality for 13 months, during this period, if spare parts of the machine were not man-made damaged, we can send the component to the customer in best delivery. Besides guarantee period, we still provide you free online services for life.If parts broken, you can order replacement parts from us.
Q4. Can you customized product according to different application?
Yes, Dapeng laser is very dedicated to combine with our current ability with the main leading supplier to offer you the customized application.
Q5:What if there are gaps in my product which need to weld?
For laser welding machines, we are usually equipped with automatic wire feeding system. For products with gaps, you can use wire feeding mechanism for wire filling welding
Q6. What is your normal lead time?
Generally standard machine, our lead time is 2-7 days after PO confirmed. Customized product need a little longer.
Q7. Will the package damaged during transportation?
Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe tranportation. We have exported to 80 countries worldwide. So please don't worry, you will receive the parcel in good condition
Q8:Why should I choose DAPENG LASER compared with other companys?
We are factory with 453 employees, turnover reached 100 millions USD in 2021, ISO 9001 certificated and most products are CE/SGS approoved, can offer you a high-quality pre-sale, in-sale and after-sales solution.*Send an inquiry and get product catalog manual!
