110V 220V Fiber Laser Marking Machine 20W-100W Multi Function

Basic Information
Place of Origin: Guangdong, China
Brand Name: DAPENG
Certification: CE, ISO
Model Number: YLP-20
Minimum Order Quantity: 1 set
Price: USD800-1600
Packaging Details: Wooden boxes that meet international export standards
Delivery Time: 5-10 days
Payment Terms: T/T
Supply Ability: 300 sets per month
Detail Information
Application: Laser Marking Working Accuracy: 0.01mm
Graphic Format Supported: AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP Laser Type: Fiber Laser
Condition: New CNC Or Not: Yes
Cooling Mode: Air Cooling Control Software: EZCAD
Laser Source Brand: Raycus Max IPG JPT Optional Weight (KG): 130 KG
Key Selling Points: High-accuracy Warranty: 2 Years
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C Marking Area: Optional
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 2 Years Core Components: Laser Source
Mode Of Operation: Pulsed Configuration: Bench-top
Feature: Deep Marking Product Name: Fiber Laser Marking Engraving Machine
Laser Source: Raycus MAX IPG JPT Laser Source Applicable Material: Metal Nonmetal Materials
Laser Power: 20W/30W/50W/100W Marking Speed: 0-8000mm/s
Laser Wavelength: 1064nm Function: Marking Logo Metal Non Metal
Working Area: 100mm-400mm (optional) Power Supply: 110V/220V Optional
After-sales Service Provided: Overseas Engineers Provide Door-to-door Service
High Light:

110V Fiber Laser Marking Machine

,

220V Fiber Laser Marking Machine

,

100W Fiber Optic Laser Marking Machine


Product Description

Dapeng 20W-100W Raycus Max IPG Mopa Metal Engraving Optical Fiber Laser Marking Machine

Product Description:

The Dapeng 20W-100W Raycus Max IPG Mopa Metal Engraving Optical Fiber Laser Marking Machine is a cutting-edge laser marking machine designed for high-precision marking applications. With its advanced technology and superior performance, this machine provides exceptional marking accuracy of 0.01mm. It is suitable for a wide range of industries, including hotels, garment shops, manufacturing plants, food and beverage factories, and more.

Features:

High-accuracy marking with a working accuracy of 0.01mm
Supports various graphic formats, including AI, PLT, DXF, BMP, Dst, Dwg, LAS, and DXP
Equipped with a reliable fiber laser source from Raycus Max IPG JPT, ensuring excellent performance
Easy operation with the user-friendly control software EZCAD
Air cooling system for efficient heat dissipation
Bench-top configuration for convenient placement
Deep marking feature for creating intricate designs
Two-year warranty for peace of mind

Technical Parameters:

Laser Type: Fiber Laser
Laser Source Brand: Raycus Max IPG JPT (Optional)
Laser Power: 20W/30W/50W/100W
Laser Wavelength: 1064nm
Marking Speed: 0-8000mm/s
Marking Area: Optional
Cooling Mode: Air Cooling
Control Software: EZCAD
CNC: Yes
Mode of Operation: Pulsed
Configuration: Bench-top
Applicable Material: Metal and Nonmetal Materials
Power Supply: 110V/220V (Optional)
Weight: 130 KG
Warranty: 2 Years

Applications:

The Dapeng Fiber Laser Marking Machine is widely used in various industries for marking logos, symbols, and texts on different materials. It is suitable for marking on metals and nonmetals, making it ideal for applications in hotels, garment shops, building material shops, manufacturing plants, machinery repair shops, food and beverage factories, and more.

Support and Services:

The machine comes with a two-year warranty to ensure customer satisfaction and peace of mind.
Overseas engineers provide door-to-door service for efficient support.
Detailed product support and services are available to assist customers in using and maintaining the machine effectively.

FAQ:

What is the lifespan of the laser source?
The laser source has a lifespan of 100,000 hours, ensuring long-lasting performance.

What file formats are supported for marking?
The machine supports a wide range of formats, including DWG, DFX, BMP, JPG, PNG, TIF, PCX, TAG, GIF, and PLT, among others.

Can the machine mark different types of barcodes?
Yes, the machine supports various barcode formats such as CODE39, EAN, CODE128, Data Matrix, PDF417, and more.

What is the power consumption of the machine?
The power consumption of the machine is ≤800W, ensuring energy efficiency.



20W-100W Raycus Max IPG Mopa Metal Engraving Optical Fiber Laser Marking Machine

110V 220V Fiber Laser Marking Machine 20W-100W Multi Function 0110V 220V Fiber Laser Marking Machine 20W-100W Multi Function 1



Laser Power 20W 30W 50W 100W Optional
Laser Source Raycus/Max/IPG/JPT MOPA
Control Board BJJCZ
Control Software EZCAD
Galvo Head Sino-Galvo
F-theta Lens 100mm-400mm Optional
Laser Lifespan 100,000 Hours
Laser Wavelength 1064nm
Marking Speed 0-8000mm/s
Power Consumption ≤800W
Cooling Mode Air Cooling
Supported characters Any fonts downloaded on computer
Supported format DWG,DFX,BMP,JPG,PNG,TIF,PCX, TAG, GIF, PLT etc..
Supported Bar code CODE39, EAN, CODE128, Data Matrix, PDF417 etc..
Cabinet Size 800*650*1420mm
Machine Weight About 130KG
Voltage 110V/220V Optional



110V 220V Fiber Laser Marking Machine 20W-100W Multi Function 2110V 220V Fiber Laser Marking Machine 20W-100W Multi Function 3110V 220V Fiber Laser Marking Machine 20W-100W Multi Function 4110V 220V Fiber Laser Marking Machine 20W-100W Multi Function 5

Our core advantages:

1) Top 5 laser company in China. Sold 4500 units of laser machines in China market per year, with best price.
2) Usually have 50 units of laser marking machine(Fiber, CO2, UV, Mopa) in stock, lead time 3-5 days.
3) Fiber Laser cutting machine, (1000W-20,000W laser cutter), usually sell 50 units/month in China.


We are looking for distributor. Price is more competitive.

We have 250MB videos and manual reference, if you want, we can send you for free, please leave message.
