| Condition: | New | Max. Output Power: | 200W |
|---|---|---|---|
| Usage: | Metal Welding | Pulse Width: | 0.3-20ms |
| Wavelength: | 1064nm | Focal Spot Diameter: | 0.3mm |
| Dimensions: | 600*1000*1210mm | Warranty: | 1 Year |
| Weight (KG): | 200 KG | Key Selling Points: | Easy To Operate |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1.5 Years | Product Name: | Jewelry Laser Welder |
| Function: | Jewelry Welding | Laser Source: | Nd:YAG |
| Positioning: | External Universal Fixture | Laser Wavelength: | 1064nm Laser Soldering |
| Power Consumption: | 200W | Cooling Method: | Water Chiller Hanli |
| Advantage: | YAG Spot Welding | Application: | Metal Stainless Steel Laser Welder |
| Keywords: | Fiber Laser Welding Equipment | Port: | China Or Shenzhen Ports |
| Highlight: | Cordless Laser Soldering Machine Jewelry,220V Laser Soldering Machine Jewelry,Silver Jewelry Welding Machine |
||
|
Model
|
DPH-200-YAG
|
|
Laser source type
|
Fiber source
|
|
Laser Out Power
|
200W
|
|
Laser wavelength
|
1070nm
|
|
Laser Source
|
YAG
|
|
Focal spot diameter
|
0.1-3mm
|
|
Laser frequency
|
1-50Hz
|
|
Repeatability
|
±0.01mm
|
|
Machine operating temperature
|
0~40℃
|
|
Electricity demand
|
220V
|
|
Cooling method
|
Water Chiller Hanli
|
|
Continuous operating time
|
24 hours
|
|
Weight
|
300kg
|
|
Dimensions
|
600*1000*1210mm
|
