Product Description:
The 200W Desktop Portable Mini YAG Jewellery Spot Laser Welding Machine is a compact and versatile welding equipment specifically designed for jewelry welding applications. It utilizes YAG laser technology to provide precise and efficient spot welding of various jewelry materials. With its portable design and user-friendly features, this machine is ideal for small-scale jewelry workshops and individual artisans.
Features:
High Power Output: With a maximum output power of 200W, this laser welding machine delivers strong welding performance for jewelry materials such as gold, silver, platinum, and copper.
Easy to Operate: The machine is equipped with user-friendly controls and interfaces, making it easy for operators to set parameters and perform welding tasks.
Adjustable Spot Size: It offers a spot adjustment range of 0.2-2mm, allowing for precise control over the welding spot size.
Compact and Portable: The desktop design and lightweight construction make it convenient for transportation and flexible usage in different workspaces.
Reliable Cooling System: The machine features an air cooling system, ensuring stable operation and preventing overheating during prolonged use.
Technical Parameters:
Laser Wavelength: 1064nm
Max. Output Power: 200W
Pulse Width: 0.1-15ms
Laser Frequency: 0-50Hz
Spot Adjustment Range: 0.2-2mm
Cooling System: Air cooling
Rated Power: 4KW
Voltage: 220V (single-phase)
Applications:
The 200W Desktop Portable Mini YAG Jewellery Spot Laser Welding Machine is specifically designed for jewelry welding applications, including:
Welding various types of jewelry, such as rings, bracelets, necklaces, and earrings.
Repairing damaged jewelry items.
Welding small components and findings in jewelry manufacturing.
Support and Services:
We provide comprehensive support and service for our customers, including:
Overseas engineers available for installation and training.
Door-to-door service for maintenance and repairs.
Technical consultation and assistance.
Availability of spare parts.
After-sales support to ensure smooth operation and customer satisfaction.
FAQ:
1.What materials can be welded with this machine?
This machine is suitable for welding jewelry materials, including gold, silver, platinum, and copper.
2.Can it be used for spot welding in other industries?
While its primary application is jewelry welding, it can also be used for spot welding small components in other industries that require precision and accuracy.
3.Is training provided for operating the machine?
Yes, we offer installation and training services to ensure customers can operate the machine effectively and safely.
4.What is the warranty period?
The machine comes with a 1-year warranty, ensuring reliable performance and customer satisfaction.
5.Can the machine be customized for specific jewelry welding requirements?
Yes, we provide customization options to meet specific needs and preferences of jewelry manufacturers and artisans.
200W Desktop Portable Mini YAG Jewellery Spot Laser Welding Machine
| Model |
DPH-100SS-YAG-W |
|
Laser wavelength
|
1064nm |
| Condenser reflector |
Imported ceramic condensing cavity
|
| Maximum laser power |
100W |
| Voltage |
220V single-phase (Voltage transformer is needed if for 110v) |
| Pulse width |
0.1-15ms |
| Laser frequency |
0-50Hz |
| Spot adjustment range |
0.2-2mm |
| Cooling system |
Air cooling |
| Rated power |
4KW |
| Packaging size(mm) |
550*860*1100mm |
| Gross weight(kg) |
100 |
| Usage environment temperature |
10-30℃ |
