| Condition: | New | Max. Output Power: | 60w |
|---|---|---|---|
| Usage: | Metal Welding | Pulse Width: | 0.1-10ms |
| Wavelength: | 1064nm | Focal Spot Diameter: | 0.1-3mm |
| Dimensions: | 435*295*510mm | Warranty: | 1 Year |
| Control System Brand: | Depeng | Weight (KG): | 40 KG |
| Key Selling Points: | Easy To Operate | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 1.5 Years | Product Name: | Jewelry Laser Welder |
| Function: | Jewelry Welding | Laser Source: | Nd:YAG |
| Positioning: | External Universal Fixture | Power Consumption: | 60W |
| Laser Wavelength: | 1064nm Laser Soldering | Advantage: | YAG Spot Welding |
| Application: | Metal Stainless Steel Laser Welder | Keywords: | YAG Laser Welding Machine |
| Port: | China Or Shenzhen Ports | ||
| Highlight: | Multipurpose Micro Jewelry Welder,60W Micro Jewelry Welder,Portable Micro Welder For Jewelry |
||
|
Model
|
DPH-60-YAG
|
|
Laser source type
|
Fiber source
|
|
Laser Out Power
|
60W-100W
|
|
Laser wavelength
|
1070nm
|
|
Laser Source
|
YAG
|
|
Focal spot diameter
|
0.1-3mm
|
|
Laser frequency
|
1-50Hz
|
|
Repeatability
|
±0.01mm
|
|
Machine operating temperature
|
0~40℃
|
|
Electricity demand
|
220V
|
|
Continuous operating time
|
24 hours
|
|
Weight
|
40kg
|
|
Dimensions
|
435*295*510mm
|
