Condition: | New | Max. Output Power: | 1000W-3000W |
---|---|---|---|
Usage: | Metal Welding | Wavelength: | 1064nm |
Warranty: | 1 Year | Control System Brand: | Depeng |
Weight (KG): | 230 KG | Key Selling Points: | Easy To Operate |
Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction Works , Energy & Mining, Advertising Company, Other | Machinery Test Report: | Provided |
Video Outgoing-inspection: | Provided | Marketing Type: | Ordinary Product |
Warranty Of Core Components: | 1.5 Years | Product Name: | Laser Welding Cutting Cleaning Machine |
Function: | Metal Part Laser Welding | Application Material: | Aluminum Stainless Steel Carbon Steel |
Cutting Materials: | Steel Iron Aluminum Carbon Steel | Welding Head: | Double Wobble Handheld Welding Head |
Power Consumption: | 1000W/1500W/2000W/3000W | Cooling Method: | Water Chiller Hanli |
Applied Industry: | Rust Remove Metal Cleaning | Laser Source: | IPG Raycus Max JPT |
Keywords: | 3 In 1 Fiber Laser Welding Equipment | Port: | China Or Shen Zhen Ports |
Highlight: | Multifunctional 1500 Watt Laser Welder,Industrial 1500 Watt Laser Welder,Durable Handheld Laser Welding System |
Model
|
DPH-1000
|
DPH-1500
|
DPH-2000
|
||
Laser source type
|
Fiber source
|
Fiber source
|
Fiber source
|
||
Function
|
3 IN 1 Handheld Fiber Laser Cleaning Welding Cutting Machine
|
|
|
||
Laser Out Power
|
1000W
|
1500W
|
2000W
|
||
Laser wavelength
|
1070nm
|
1070nm
|
1070nm
|
||
Laser Source
|
Raycus/Max/IPG/nLIGHT
|
Raycus/Max/IPG/nLIGHT
|
Raycus/Max/IPG/nLIGHT
|
||
Focal spot diameter
|
0.1-3mm
|
0.1-3mm
|
0.1-3mm
|
||
Laser frequency
|
1-50Hz
|
1-50Hz
|
1-50Hz
|
||
Repeatability
|
±0.01mm
|
±0.01mm
|
±0.01mm
|
||
Machine operating temperature
|
0~40℃
|
0~40℃
|
0~40℃
|
||
Electricity demand
|
220V
|
220V
|
220V/380V
|
||
Cooling method
|
Water Chiller Hanli
|
Water Chiller Hanli
|
Water Chiller Hanli
|
||
Continuous operating time
|
24 hours
|
24 hours
|
24 hours
|
||
Weight
|
230kg
|
230kg
|
230kg
|
||
Dimensions
|
100*100*172cm
|
100*100*172cm
|
100*100*172cm
|
||
Laser control system
|
Depeng Touch screen
|
Depeng Touch screen
|
Depeng Touch screen
|
